Non-contact sensing technology, without mechanical wear
Electromagnetic Eddy Current Sensor Module
EDP
The core function of the EDP sensor is to precisely measure the rotation angle of the motor rotor, in order to ensure the accuracy of motor control
Features
01
Low cost, simpler design
02
No need for magnetic steel, avoiding magnetic interference issues
03
产品参数
| Dimension | -- |
| Force Range | -- |
| TP Transmission/Reception | -- |
| TP Accuracy | -- |
| Tactile Vibration lifespan | -- |
| Tactile Noise | -- |
| Power Supply | -- |
| Power Supply Voltage | 4.5 V DC - 5.5 V DC |
| Current Consumption | < 20mA |
| Output Signal | Analog differential sine and cosine (Sin/Cos) |
| External Communication | -- |
| Output Current | -- |
| Rated Output Values at 40°C for Each Channel | -- |
| AC Operating Voltages | -- |
| DC Control input | -- |
| Channel | -- |
