Design of an integrated, high-performance onboard antenna
Integrated Wi-Fi6 Module
Wi-Fi6-01
This module integrates a 2T2R RF module, buttons, a USB 2.0 interface, and IEEE 802.11a/b/g/n/ac/ax functionality, making it suitable for high-throughput performance applications
Features
01
Supports DC 5V–12V power supply compatibility design
02
Support FPC connector design
03
Supports optional external antenna or onboard antenna compatible design
04
Integrated touch button reset function
05
Specifications
| Type | -- |
| Function | -- |
| IP Rating | -- |
| Dimension(mm) | -- |
| Product Certification | SRRC |
| Working Voltage | DC 5V/2A, 12V/1A |
| Operating Temperature | -10 to 70°C |
| Antenna Type | -- |
| Operating Frequency | -- |
| Ports Type | -- |
| Polarization | -- |
| Side Lobe Level | -- |
| Feeding Type | -- |
| Size(L*W*H) | -- |
| Weight | -- |
| Working Temperature | -- |
| Working Frequency Bands | 2.4 GHz + 5 GHz |
| Working Bandwidth | 2.4 GHz to 20/40 MHz, 5 GHz to 20/40/80 MHz |
| Working Protocols | IEEE802.11a/b/g/n/ac/ax |
| Operation Mode | STA/AP/P2P |
| Security Encryption Protocol | WFA WPA/WPA2/WPA3 personal, WPS2.0, WAPI |
| Frequency Range | -- |
| Channel BW | -- |
| Direction of Polarization | -- |
| Antenna Scale | -- |
| Horizontal Scanning | -- |
| Vertical Scanning | -- |
| Total Power Consumption | -- |
